GPS Receiver Antenna with TNC Female Connector for Satellite Navigation Systems - Compatible with Beidou 2 GPS GLONASS - IP68 Rated 4 Star Full Frequency - DC 3.3-16V

Item Type: AntennaWorking Frequency Band: BDS: B1A, B1I, B1C, B2I, B2a, B2b, B3A, B3AE, B3QGPS: L1, L2, L5GLONASS: G1, G2, and G3GALILEO: E1, E5a, E5b, E6ABAS: L1, L5QZSS: L1, L2, L5, L6IRNSS: L5L BandFrequency Range: 1166MHz-1278MHz, 1521MHz-1608MHzImpedance: 50ΩPolarization Mode: Right Hand Circular Polarization (RHCP)Horizontal Covering Angle: 360 DegreeOutput Standing Wave: 2Maximum Gain: 5dBiAntenna Axial Ratio: Phase Center Error: ±2mmLow Noise Amplifier Indicator: Gain: 40dB±2dBNoise Factor: 2dBOutput Standing Wave: 2Output Impedance: 50ΩIn band Flatness: ±2dBOutput P1 Compression Point: 0dBmWorking Voltage: DC 3.3-16VWorking Current: 45mA (Typical Value)Differential Transmission Delay: 5nsAntenna Size: Approx. 150 x 58.4mm / 5.9 x 2.3inConnector Type: TNC-KBottom Mounting Thread: Centering Rod MountingMounting Thread Specification: Coarse Thread 5/8in-11, Depth 12-14mm / 0.47-0.55inOperating Temperature: -40℃ to +85℃Storage Temperature: -55℃ to +85℃Humidity: 95% Non CondensingProtection Grade: GB/T4208-2017-IP68 (test condition is 1 meter water depth continuous soaking for 2 hours normal work)Shell Overall Compressive Strength: 12.24kgf/cm²Package List：1 x Antenna1 x Mount1 x 8 Meter Cable

• Multi System Satellite Support: This external full band measurement antenna receives satellite navigation signals from Beidou 2, GPS, and GLONASS systems for geodesy, oceanography, and agricultural applications.
• Phase Center: The antenna utilizes a single layer multi feed ultra wideband design to minimize phase center elevation differences for improved measurement precision in professional positioning tasks.
• Low Elevation Signal Reception: High gain and small gain roll off characteristics allow for reliable satellite signal collection at low elevations while reactive power network suppression reduces multipath signal interference.
• Integrated Low Noise Amplifier: An integrated low noise amplifier with pre filtering technology suppresses out of band interference signals to enhance reliability and maintain signal integrity across frequencies.
• Rugged : This IP68 rated and antenna features a cover and a shell with 12.24 kgf per square centimeter compressive strength for long term outdoor performance at DC 3.3 - 16V.
